This system can be configured to inspect:
Dimensions
Outer diameter
Height
Other customer-specified measurementsSurface Defects
Cracks
Scratches
Blockages
Additional visible flaws based on product type
Ensure every ceramic component meets strict quality standards, reach out to learn how this solution can support your production goals.


General | Power | 1.8 kW | |
Air pressure | 0.4-0.6Mpa,air inlet pipe Ø16mm | ||
Machine dimensions | 1100(L)×1700(W)×1800(H)mm | ||
Machine weight | 350kg | ||
Working conditions | Less than 90% RH | ||
Visual inspection | Inspection speed | Design speed: 80-3000 pcs/min | |
CDD Camera | Image sensor | Basler (German) | |
Resolution | 2560×1920,1280×1024 | ||
Inspection accuracy | ±0.01mm | ||
Lens | Optical lens | Custom lens | |
Depth of field (DoF) | 0.2-3mm | ||
Light source | AOI light source | ||
Feeding | Precision belt feed system | Precision belt is made from special conductive material through integrated forming process,ensuring high accuracy (customized) |
